COMPUTER HARDWARE AND NETWORKING
L T P C
PRACTICUM 1 0 4 3
UNIT I COMPUTER HARDWARE
Introduction: Hardware, Software and Firmware. Mother board components, SMPS:
Principles of Operation and block diagram of ATX Power Supply, Connector
Specifications
4
Processors, Memory: Introduction-Main Memory, Cache memory Secondary Storage:
Hard Disk – SSD – Format, Partition
I/O devices and interface keyboard-Mouse-Printers-Scanner-Displays Graphic Cards
Ex.No Name of the Experiment
1
Assemble and disassembling a computer & Troubleshooting (Study
Experiment)
Hard Disk/SSD
(a) Partition and Format.
(b) Scan Disk, Disk Cleanup, Disk De-Fragmentation
6
UNIT II OPERATING SYSTEM AND PERIPHERAL DEVICE INSTALLATION
Operating System-Server OS Installation, User Creation, Disk Cleaning,
Defragmentation. Peripheral device (Scanner, Web cam, and bio-metric Installation
& Updating of Device Driver Software.
2
Ex.No Name of the Experiment
2
Install and configure any one device (Printer, Scanner, Web cam,
bio-metric device) with system and troubleshoot the problems.
6
3 Windows Server OS installation 6
UNIT III ADMINISTERING WINDOWS SERVER
Active directory – Use f Ad-Installation & Configuration of AD, Domain Name
Service Use of DNS-Installation and Configuration of DNS. Web Server – Installation
and Configuration of IIS web Server – HTTP Protocol Usage. FTP Server –
Installation & Configuration of FTP Server – FTP Protocol Usage. SMTP Serve –
Installation & Configuration of SMTP Server
3
(v)
Ex.No Name of the Experiment
4. Installation and configuration of DNS Server 6
5. Installation and configuration of DHCP Server 6
6. Installation and configuration of any one of service (Telnet, FTP Server,
Web server)
6
UNIT IV NETWORK DEVICES
Network Devices: Cable, Cable Crimping (Cross, Straight Through Cabling), Switch
– Features and concepts of Switches – Routers (Wired and Wireless) – Gateways.
6
IP Addressing: Dotted Decimal Notation – Subnetting & Supernetting, Data backup
and data recovery, Firewall, VPN
Ex.No Name of the Experiment
7. Practice the following cabling works in a network
(a) Cable Crimping
(b) Standard Cabling
(c) Cross Cabling
(d) Testing the Crimped cable using a Cable tester
6
8. Create a Network topology using any network simulation software 6
9. IP Configuration & Testing
(a) Configure Host IP, Subnet Mask and Default Gateway in a system
in LAN (TCP/IP Configuration) (b) Configure Internet connection and
use IPCONFIG, PING /Tracert and Netstat utilities to Debug the Network
issues
6
10. Data Backup & Network Security
(a) Create and configure user accounts (Administrative and Standard)
in Windows
(b) Create automated backups to ensure no data loss & you always
have a recent backup
(c) Create rules on firewall to allow clients to connect to the Server
Service
6
TOTAL PERIODS 75
