1020234320 ADVANCED MANUFACTURING
TECHNOLOGY PRACTICAL
Syllabus Contents
Introduction
Study of CNC lathe, milling. – Study of international standard codes:G-Codes and
M-Codes. – Format – Dimensioning methods. – Program writing –Turning simulator –
Milling simulator, IS practice – commands menus. – Editing the program in the CNC
machines. – Set the machine and execute the program in the CNC machines
Introduction – 3D printing – modelling software- slicing software -parameters like layer
thickness- orientation and infill on build time
Robotics – introduction – types – configurations – joints – degrees of freedom – industrial
applications – robot analyzer software – feature
Practical Exercises
CNC Turning Machine Material: M.S / Aluminium / Acrylic fibre / Plastic
1. . Using Linear and Circular interpolation – Create a part program and produce
component in the Machine
2. Using Stock removal cycle – Create a part program for multiple turning operations
and produce component in the Machine.
3. Using canned cycle – Create part program for thread cutting,grooving and produce
component.
CNC Milling Machine Material: M.S / Aluminum / acrylic fibre / plastic
4. Using Linear interpolation and Circular interpolation – Create a part program for
grooving and produce component in the Machine.
5. Using canned cycle – Create a part program for drilling produce component in the
Machine
6. Using subprogram – Create a part program and produce the component in the
Machine.
7. Model the given engineering component and prepare the .stl file to print using a
3D printer or simulator. – Geneva Wheel
8. Model the given engineering component and prepare the .stl file to print using a
3D printer or simulator. – C Clamp with V Block.
9. Position and record the point to point motion of the robot arm or in a simulator.
(5 Positions)
10. Position and record the continuous motion of the robot arm or in a simulator.
(The profile should have Straight line, Circular and inclined line)
