SYLLABUS
1010236242 – STRUCTURAL DETAILING FOR RCC ELEMENTS
UNIT – I : DETAILING OF SIMPLY SUPPORTED, SINGLY AND DOUBLY REINFORCED BEAMS
AND CANTILEVER BEAMS AS PER IS 456- 2000
Concept of Reinforced Cement Concrete (RCC)–Types of Reinforcement Materials
Suitability of steel as reinforcing material-Properties of mild steel, HYSD steel
and TMT bars-Loading on structures as per IS:875 -Development of stress in
reinforcementCurtailment of reinforcements -Detailing and drafting Concept of
simply supported singly and doubly reinforced beams and cantilever beams as per
IS456 -2000.
Practical Exercises:
1. Detailing and Drafting of Singly Reinforced simply supported beam as per
codal provisions.
2. Detailing and Drafting Doubly Reinforced simply supported beam as per
codal provisions.
3. Detailing and Drafting of cantilever beam as per codal provisions.

UNIT – II : DETAILING OF ONE WAY, TWO WAY AND CONTINUOUS SLABS AS PER IS 456- 2000
Requirements governing slab reinforcements and detailing of slabs as per IS 456 –
2000 – Detailing and drafting of one way, two way slab (Corners are not held down
and corners held down) – Tension and Torsion reinforcement requirements.
Practical Exercises:
4. Detailing and drafting of one-way slab as per codal provisions.
5. Detailing and drafting of two-way slab as per codal provisions- Corners
are notheld down (All the Four edges discontinuous case )
6. Detailing and drafting of two-way slab as per codal provisions corners
held down (All the Four edges discontinuous case )
7. Detailing and drafting of one-way Continuous slab as per codal provisions.
8. Detailing and drafting of two-way Continuous slab as per codal provisions.
UNIT – III : DETAILING OF COLUMNS AND FOOTING AS PER IS 456- 2000
Requirements governing longitudinal and transverse reinforcement of column as
per IS 456 – arrangement of transverse and longitudinal reinforcement as per IS
456 – detailing and drafting of axially loaded short columns for reinforcement
distributed equally on two/four sides and footing as per IS code.
Practical Exercises:
9. Detailing and drafting of square column as per codal provisions.
10. Detailing and drafting of rectangular column as per codal provisions.
11. Detailing and drafting of isolated square footing as per codal provisions.
12. Detailing and drafting of isolated rectangular footing as per codal provisions
