1010235320                          COMPUTER APPLICATIONS IN CIVIL ENGINEERING [PRACTICAL]

Part A ELECTRONIC SPREAD SHEET USING SOFTWARE
1. Prepare the Estimate and Abstract sheet with given data (provide all the
measurement details) and calculate the quantity and Total Amount using
formula bar.
4
2. Calculate Effective depth “d” and Area of Steel “Ast” using Formula Bar
for given singly reinforced section.
4
3. Finding centre of gravity; Ixx and IYY of I, L, T and channel sections. 4
4. Calculate Area and Elongation using formula bar 4
Part B ANALYSIS OF RCC STRUCTURES
Note:
Analyse the Structure using any one of the available Software Packages-
Staadpro, SAP, etabs, Tekla, Cads3d etc.)
5. Carryout the analysis of Continuous Beam with given size 6
6. Carryout the analysis of Portal Frame structure with given size 6
7. Carryout the analysis of king post roof truss 8
8. Carry out the analysis and design of 1 BHK residential house with given
structure
6
Part C DRAFTING OF RCC STRUCTURES
Note:
Draw the Structure using any one of the available 3D drafting Software
Packages – Autodesk Revit Architecture, ArchiCAD, Autodesk Civil3D,
Sketchup etc.)
9. Preparation of plan, section and elevation of a House with single bed
room and attached bathroom with R.C.C. flat roof (Framed structure)
8
10. Preparation of plan, section and elevation of a Single storied School
building with R.C.C flat roof (Framed structure)
